title: "Hypothesis Tests for Population Proportions"
author: "Evan L. Ray"
date: "November 6, 2017"
output: ioslides_presentation
---

<script type="text/x-mathjax-config">
    MathJax.Hub.Config({
        "HTML-CSS": { scale: 90, linebreaks: { automatic: true } },
        SVG: { linebreaks: { automatic:true } },
        displayAlign: "left" });
</script>


<style>
  .col2 {
    columns: 2;         /* number of columns and width in pixels*/
    -webkit-columns: 2; /* chrome, safari */
    -moz-columns: 2;    /* firefox */
  }
  .col3 {
    columns: 3 100px;
    -webkit-columns: 3 100px;
    -moz-columns: 3 100px;
  }
</style>

```{r setup, include=FALSE}
knitr::opts_chunk$set(echo = FALSE, cache = FALSE)
require(ggplot2)
require(scales)
require(dplyr)
require(tidyr)
require(readr)
require(mosaic)
```

<style>
  slides > slide > hgroup + article {
    margin-top: 10px;
  }
</style>

## Is Paul the Octopus Psychic?

Recall our procedure for hypothesis testing:

1. Collect **data**: for each of 8 trials, was the prediction correct?
2. Calculate a **sample statistic** (called the test statistic):
    * $x =$ total number correct (8 in our case)
3. Obtain the **sampling distribution** of the test statistic, assuming a **null hypothesis** of no effect (in this case, assuming Paul is just guessing)
4. Calculate the **p-value**: probability of getting a test statistic "at least as extreme" as what we observed in step 2
5. If the p-value is low, reject the null hypothesis and conclude that Paul is psychic!


## More Carefully...

* **Test Statistic**: $x = 8$ (observed number correct)
* **Null Hypothesis**: Paul was just guessing: $p = 0.5$
* **Alternative Hypothesis**: Paul is psychic: $p > 0.5$
* **Sampling Distribution**, assuming null hypothesis is true:

<div class="col2">
$$X \sim \text{Binomial}(8, 0.5)$$
(check assumptions!)

* **p-value**:

$$P(X \geq 8) = 0.0039$$

```{r, echo = FALSE, fig.height=2.25, fig.width=3.3}
Paul_success_probs <- data.frame(
  num_successes = seq(from = 0, to = 8),
  pv = factor(c(rep(0, 8), 1)),
  probability = dbinom(x = seq(from = 0, to = 8), size = 8, prob = 0.5))

ggplot() +
  geom_col(mapping = aes(x = num_successes, y = probability, fill = pv),
    data = Paul_success_probs) +
  xlab("Number of Successes") +
  scale_fill_manual("p-value", values = c("black", "red"))
```

</div>

* **Conclusion**: It's unlikely that Paul would get 8/8 right if he was just guessing, so we reject the null hypothesis and conclude that he is psychic!

## IMPORTANT FACT!!!

<div class="col2">

<img src="PTPO_FINALv3_Paul Sullivan_small.jpg" width = "100%" height="50%" />

* Hypothesis tests are **guaranteed** tell you the wrong thing sometimes!!!!!!!!!!!!!!!!
* This is similar to the fact that confidence intervals are **guaranteed** to miss the population parameter sometimes.
* More on this in a few days.

<span style="font-size: 10px">
(image credit: Paul J. Sullivan)
</span>

</div>

## More on Hypotheses

* **Null Hypothesis**: (Short Hand: $H_0$)
    * Nothing has changed since the past...
    * People are just guessing...
    * Nothing interesting is going on...
    * $p =$ (proportion from the past)/(chance of being right if just guessing)/(etc...)
* **Alternative Hypothesis**: (Short Hand: $H_A$)
    * Times have changed!
    * People know what they're doing!
    * The world is fascinating!
    * $p \neq$ (value from null hypothesis)
    * $p >$ (value from null hypothesis)
    * $p <$ (value from null hypothesis)

## Examples of Hypotheses

 * Paul the Octopus, 8 right out of 8
    * Null Hypothesis ($H_0$): $p = 0.5$
    * Alternative Hypothesis ($H_A$): $p > 0.5$
 * Proportion of M and M's that are blue (concerned it's lower now!); 12 blue out of 100
    * Null Hypothesis ($H_0$): $p = 0.16$
    * Alternative Hypothesis ($H_A$): $p < 0.16$
 * The National Center for Education Statistics released a report in 1996 saying that 66% of students had missed at least one day of school in the past month.  A more recent survey of 8302 students found that 5562 of them had missed at least one day of school.  Has the rate of absenteeism changed?
    * Null Hypothesis ($H_0$): $p = 0.66$
    * Alternative Hypothesis ($H_A$): $p \neq 0.66$

## More on P-Values

 * **p-value**: probability of getting a test statistic "at least as extreme" as what we observed, assuming $H_0$ is true
 * What counts as "at least as extreme" depends on the form of the alternative hypothesis


## P-Values for One-Sided Tests

<div class="col2">
<div>
* Paul predicts 8 of 8 correctly
* $H_0$: $p = 0.5$
* $H_A$: $p > 0.5$
* **p-value**: $P(X \geq 8) = 0.0039$
 if $X \sim \text{Binomial}(8, 0.5)$
```{r, echo = FALSE, fig.height=3.5, fig.width=3.75}
Paul_success_probs <- data.frame(
  num_successes = seq(from = 0, to = 8),
  pv = factor(c(rep(0, 8), 1)),
  probability = dbinom(x = seq(from = 0, to = 8), size = 8, prob = 0.5))

ggplot() +
  geom_col(mapping = aes(x = num_successes, y = probability, fill = pv),
    data = Paul_success_probs) +
  xlab("Number of Successes") +
  scale_fill_manual("Included\nin p-value", labels = c("No", "Yes"), values = c("black", "red"))
```
</div>

<div style="display: inline-block;">
* 12 Blue M\&M's out of 100
* $H_0$: $p = 0.16$
* $H_A$: $p < 0.16$
* **p-value**: $P(X \leq 12) = 0.1703$
 if $X \sim \text{Binomial}(100, 0.16)$
```{r, echo = FALSE, fig.height=3.5, fig.width=3.75}
Paul_success_probs <- data.frame(
  num_successes = seq(from = 0, to = 100),
  pv = factor(c(rep(1, 13), rep(0, 88))),
  probability = dbinom(x = seq(from = 0, to = 100), size = 100, prob = 0.16))

ggplot() +
  geom_col(mapping = aes(x = num_successes, y = probability, fill = pv),
    data = Paul_success_probs) +
  xlab("Number of Successes") +
  scale_fill_manual("Included\nin p-value", labels = c("No", "Yes"), values = c("black", "red"))
```
</div>
</div>

## P-Values for Two-Sided Tests

* 5562 out of 8302 students missed at least one day of school.
* $H_0$: $p = 0.66$, $H_A$: $p \neq 0.66$
* If $H_0$ is true, $X \sim \text{Binomial}(8302, 0.66)$
* "At least as extreme": at least as far from the expected value
* $E(X) = np = 8302 * 0.66 = 5479.32$

<div class="col2">
```{r, warning=FALSE, echo = FALSE, fig.height=2, fig.width=4}
Paul_success_probs <- data.frame(
  num_successes = seq(from = 0, to = 8302),
  pv = 0,
  probability = dbinom(x = seq(from = 0, to = 8302), size = 8302, prob = 0.66))

diff <- 5562 - 5479
Paul_success_probs$pv[Paul_success_probs$num_successes >= 5562] <- 1
Paul_success_probs$pv[Paul_success_probs$num_successes <= 5479  - diff] <- 1
Paul_success_probs$pv <- factor(Paul_success_probs$pv)

ggplot() +
  geom_col(mapping = aes(x = num_successes, y = probability, fill = pv),
    data = Paul_success_probs) +
  geom_vline(mapping = aes(xintercept = xintercept), color = "red", linetype = 2, data = data.frame(xintercept = 5479.32)) +
  xlab("Number of Successes") +
  scale_fill_manual("Included\nin p-value", labels = c("No", "Yes"), values = c("black", "red"))
```


```{r, warning=FALSE, echo = FALSE, fig.height=2, fig.width=4}
Paul_success_probs <- data.frame(
  num_successes = seq(from = 0, to = 8302),
  pv = 0,
  probability = dbinom(x = seq(from = 0, to = 8302), size = 8302, prob = 0.66))

diff <- 5562 - 5479
Paul_success_probs$pv[Paul_success_probs$num_successes >= 5562] <- 1
Paul_success_probs$pv[Paul_success_probs$num_successes <= 5479  - diff] <- 1
Paul_success_probs$pv <- factor(Paul_success_probs$pv)

ggplot() +
  geom_col(mapping = aes(x = num_successes, y = probability, fill = pv),
    data = Paul_success_probs) +
  geom_vline(mapping = aes(xintercept = xintercept),
    color = "red",
    linetype = 2,
    size = 1,
    data = data.frame(xintercept = 5479.32)) +
  xlab("Number of Successes") +
  xlim(c(5250, 5700)) +
  scale_fill_manual("Included\nin p-value", labels = c("No", "Yes"), values = c("black", "red"))
```
</div>

* R actually does something slightly different, but the results will usually be the same as what's described here.

## Calculation of P-Values in R

* Suppose we have a data frame with a variable indicating success/failure:
```{r, echo = FALSE}
paul_guesses <- data.frame(result = rep("correct", 8))
```
```{r, echo = TRUE}
paul_guesses
```

## Calculation of P-Values in R (Cont'd)

* One-sided: $H_A$: $p > 0.5$

```{r, echo = TRUE}
binom.test(paul_guesses$result,
  success = "correct",
  p = 0.5,
  alternative = "greater")
```

## Calculation of P-Values in R (Cont'd)

* One-sided: $H_A$: $p < 0.16$
* Suppose we know the number of trials ($n = 100$ M\&M's) and number of successes ($x = 12$ blue)

```{r, echo = TRUE}
binom.test(x = 12,
  n = 100,
  p = 0.16,
  alternative = "less")
```

## Calculation of P-Values in R (Cont'd)

* Two-sided: $H_A$: $p \neq 0.66$
* Suppose we know the number of trials ($n = 8302$ students) and number of successes ($x = 5562$ missed school)


```{r, echo = TRUE}
binom.test(x = 5562,
  n = 8302,
  p = 0.66,
  alternative = "two.sided")
```

## Drawing Conclusions

 * **p-value**: probability of getting a test statistic at least as extreme as what we observed, assuming $H_0$ is true
    * e.g., probability of getting at least 8 predictions right if Paul is just guessing
 * If the p-value is **small**, that is evidence that the null hypothesis may not be true

## Drawing Conclusions

 * **p-value**: probability of getting a test statistic at least as extreme as what we observed, assuming $H_0$ is true
    * e.g., probability of getting at least 8 predictions right if Paul is just guessing
 * If the p-value is **small**, that is evidence that the null hypothesis may not be true
 * If we need to make a decision about whether or not the null hypothesis is true, we can see whether the p-value is smaller than a cutoff of our choosing
 * The cutoff is the **significance level** of the test
 * Denote the significance level by $\alpha$ (alpha)
 * A common significance level: $\alpha = 0.05$
 * But this choice is arbitrary

## Drawing Conclusions

 * If the p-value $< \alpha$, we "reject" $H_0$: the data offer enough evidence to conclude that $H_0$ is not true at the significance level $\alpha$.
 * If the p-value $\geq \alpha$, we "fail to reject"" $H_0$: the data **don't** offer enough evidence to conclude that $H_0$ is not true at the significance level $\alpha$.

## Note About the Book

* The procedure described in these slides is different from what's in the book.
* Our method uses
    * **sample statistic** = number of successes in the sample
    * **sampling distribution** = modeled with a Binomial
* The book's method uses
    * **sample statistic** = proportion of successes in the sample
    * **sampling distribution** = modeled with a Normal
* Everything else is the same (hypotheses, p-values, conclusions), and both methods are valid.
* Our procedure requires less work:
    * fewer assumptions to check (more broadly applicable)
    * fewer computations (e.g. no need to calculate $\sqrt{p(1-p)/n}$)
